We have engineered hundreds of conveyors for projects across the world.

From long-distance cross-country systems to complex port terminals and brownfield retrofits.

Here are some highlights that reflect our capabilities and versatility.

Domestic Projects

  • Engineering of Transnational Long Belt Conveyor System, Lafarge Cements

    Length: ~17.1 km Single Flight

    Material: Limestone

    Capacity: 800 TPH

    Belt Speed: 4 m/s

    Maintenance Vehicle: 2 Nos

    Lift: (-) 58.5 m-Horizontal & vertical curves

  • Engineering of Pipe Conveyor for Recirculation Coke System, Tata Steel

    Stacking Path: Reclaiming Path:

    Capacity: 500 TPH Capacity: 500 TPH

    Length: 400 m. Length:400m

    Lift: 30 m. Lift: 10m

    Pipe dia: 550 mm. Pipe dia: 550mm

  • Engineering of Pipe Conveyor System for IISCO RMHS

    Coke Conveyor Iron Ore & Flux Conveyor

    Capacity: 200 TPH Capacity: 600 TPH

    Length: 1485m Length: 1355m

    Lift: 12.6m Lift: 4m

    Pipe Dia: 300mm Pipe Dia: 300mm

  • Engineering of Pipe Conveyor System for Uttam Infra Logix Limited

    Client: Jindal Steel & Power Limited (Tamnar)

    Length: 20 kms (2 Nos ~7.5 kms long & 1 No ~5km long)

    Material: Coal

    Capacity: 2000 TPH

    Belt Speed: 4.5 m/s

    Pipe Dia: 550m

    Maintenance Vehciles: 6 Nos

  • Techno-Economic Study of an Ultra Mega Power Plant Project for Adani Infra (India) Limited

    Key Highlights

    Length: Route A : ~28 km & Route B: ~ 24 km

    Capacity: 23 MTPA of Coal

    Belt Speed: > 6 m/s

    Drive:  @ Head, Tail & Intermediate Booster stations.

    14 Nos. of Alternatives were proposed out of which 6 were taken for detailed commercial study

    Survey details were taken through geospatial surveying software like Infraworks & Google Earth Pro.

    Bridges over Ib River crossing  (~ 1.2 km Long)

  • Engineering Belt Conveyor System & Travelling Tripper for IWA- Sahibganj

    Client: L&T Geo

    Material: Coal & Stone Chips

    Capacity: 1200 TPH

    Belt Speed: 2.5m/s

    Belt Width: 1400mm

    Travelling Tripper: 1 Nos

  • Engineering for External Coal Handling System- TANGEDCO Ennore Port

    Client: TANGEDCO, CREW-PL

    Material: Coal

    Capacity: 4000 TPH

    Belt Speed: 4.0 m/s

    Belt Width: 2000 mm

  • Engineering for Mechanization of Berth-6 at Krishnapatnam Port

    Client: Adani Ports & SEZ Limited

    Material: Coal

    Capacity: 4000 TPH

    Belt Speed: 4.0 m/s

    Belt Width: 2000 mm

  • Engineering of Conveyors of IB Valley 10 MTPA Coal Washery Project for Mahanadi Coal Fields Limited

    Client: Global Coal & Mining Pvt. Ltd

    Material: Coal

    Length: 6.85 km

    Belt Speed: 2 m/s to 2.5 m/s

    Trippers: 2 Nos

    Shuttle Feeder: 1 Nos

  • Engineering Verification and Reverse Engineering for Existing Conveyor System at Adani Krishnapatnam Port

    Ensure existing conveyor & TT GA Drawings match the existing installed  system. In case of discrepancies, the revised As-Built drawings were submitted.

    Performed stability checks of existing galleries, trestles & towers which including  strengthening scheme along with details drawings if structural members were not within permissible limits.

  • Engineering of Conveyors for 4 MTPA Iron Ore Pellet Plant

    Client: Tata Steel Ltd.,

    Material: Iron Ore

    Length: ~3.3 kms

    Belt Speed: 1.2 m/s to 2.4 m/s

International Projects

  • Design & Basic Engineering of Long Belt Conveyor for Vicat Cements, France

    Length: ~6.25 km

    Capacity: 1000 TPH

    Material: Limestone

    Belt Speed: 3 m/s

    Curves: 5 Nos.(Min Radius 510 m)

    Concrete Walls: 10 km

  • Design & Basic Engineering of Long Belt Conveyor for Ijaci Plant, Camarago, Brazil

    Length: ~1.5 kms

    Capacity; 1300 TPH

    Material: Limestone

    Belt Speed: 4.5m/s

    Belt Width: 1000mm

  • Design & Engineering for Long Belt Conveyor for Indorama- Industries Chimiques du Senegal, Senegal

    Client: Indorama-ICS, Tata Consulting Engineers

    Material: Rock Phosphate

    Capacity: 2000 TPH

    Belt Speed: 5.4 m/s

    Belt Width: 1200 mm

    Length: 3.9 km, (with Horizontal and Vertical curves)

  • Balance Engineering, Troubleshooting and Augmentation Engineering for Tanjung Bin Power Plant, Malaysia

    Client: Melewar Engineering.

    Material: Coal

    Capacity: 5000 TPH

    Belt Speed: 4.6 m/s

    Belt Width: 1800 mm

  • Design and Engineering of Downhill Conveyor for Cosmos Cementos , Spain

    Length: 1.2kms

    Drop: 174m

    Capacity: 1300 TPH

    Material: Limestone

  • Design & Basic Engineering, including dynamic analysis of Long Belt Conveyor for Guinea Alumina Corporation, Guinea

    Client: Guinea Alumina Corporation, Tata Consulting Engineers Limited

    Length: ~2.8 kms

    Capacity: 10000 TPH

    Material: Bauxite

    Belt Speed: 5.4 m/s

    Belt Width: 1800 mm

  • Front End Engineering and design for Sulphuric Handling System, RAPID Project Petronas, Malaysia

    Client: RAPID Project Petronas

    Scope: Front End Engineering and Design for sulphur handling system including Dumper Unloading Station, Conventional and Pipe Conveyors, Stacker, Portal Reclaimers and Ship Loaders
